Dual System 86 Inch Interactive Touch Intelligent Nano Blackboard
Intelligent Nano Blackboard is a modern and technologically advanced tool designed specifically for school education. It is a digital board that replaces traditional chalkboards and whiteboards. It is a high-resolution LED screen that can be mounted on the wall in a classroom or academic setting.
The Intelligent Nano Blackboard comes with several features that make teaching and learning easier and more engaging:
First and foremost, the blackboard has touch screen technology, which allows teachers and students to interact with the board using their fingers or a digital pen. This feature makes it possible to write, draw, and annotate directly on the board, making it ideal for brainstorming, problem-solving, and idea sharing.
The Intelligent Nano Blackboard also comes with an advanced software system that enables teachers to access and share teaching materials directly from their computers, tablets or smartphones. The software system also comes with pre-installed teaching aids like diagrams, graphs, and images that can be used to explain difficult concepts in a simple and visual way.
Another key feature of the Intelligent Nano Blackboard is the ability to record and save lessons. Teachers can record their lessons and store them for future reference or share them with absent students or those who did not understand the lesson.
Overall, the Intelligent Nano Blackboard is an innovative educational tool that is ideal for modern classrooms. With its advanced features, the blackboard can enhance the teaching and learning experience of students and teachers alike.
Product Parameters in details of Interactive Touch Intelligent Nano Blackboard:
| Model Name | Intelligent Nano Blackboard |
| Size | 86inch (75inch, 98inch, optional) |
| Screen Resolution | 4K: 3840*2160 / 60Hz |
| Max Brightness | 400nits |
| Default System | Android 11 |
| CPU | Amlogic 982, Quad core A55*4, 1.9GHz |
| GPU | Mali-G52 |
| RAM+ROM | 4G+32G |
| WIRELESS | WiFi: 2.4G + BT / Hotspot: 2.4G + 5G |
| Screen sharing App | 4 screens sharing (9-screen sharing optional) |
| Default APP | Whiteboard / Google Play Store / Google Chrome / etc |
| OPS support | 4K: 3840*2160 / 30Hz |
| OPS' Max Input Supported | 55/65 inch,110W≤POWER CONSUMPTION;
75/86/100 inch,150W≤POWER CONSUMPTION |
| Touch Points | Multitouch: Android 20 Ponits |
| AG Glass | Anti-glare 4mm |
| Viewing angle | H178/V178 |
| Loud Speaker | 8Ω 15W *2 |
| Front I/O | HDMI in *1, Touch USB *1, Type-C *1, USB * 3, Power button *1 |
| Rear I/O | HDMI in *2, AV IN *1, AV OUT *1, SPDIF out *1, Earphone * 1, RJ45 *1, USB2.0 *1, USB3.0 *1, HDMI out *1, RS232 UART *1, Touch USB *1, [ VGA *1 + YPBPR *1 + VGA Audio IN *1 optional ] |
| Weight & Size | 86kg + 52kg, interactive blackboard: 225*21*143cm
normal blackboard: 115*25*142cm |
| Standard Accessories | Interactive board, normal blackboard *2, Wall mount bracket, AC power charger, Remote control, 2pcs Magnetic pens |
| OPTIONAL functions | 13MP/ 48MP Camera + 8 array Microphone, Dual 5G, HDMI OUT, Wifi 6, Type-C, etc |
| Function & Application | * Support function DMS (one main device to control all devices) * Mainly for school education |
